DESCRIPTION

• Hands free automatic grind, dose and tamp. Automatically grinds, doses and tamps the required amount of coffee, mess free.
• Grind size dial. Adjustable grind settings from fine to coarse for optimal espresso extraction.
• Stainless steel conical burrs. Maximize ground coffee surface area for a full espresso flavour.
• Automatic hands free milk texturing. Automatically textures milk to the selected temperature and style from silky smooth latte to creamy cappuccino. Automatic purge removes residual milk from the steam wand when returned to the downward position.
• Simultaneous coffee & steam. Dedicated stainless steel espresso and steam boilers for simultaneous milk texturing and espresso extraction.
• Electronic PID Temperature control. Electronic temperature control delivers precise water temperature for optimum espresso flavour. Programmable.
• Actively heated group head. Commercial size 58 mm group head with embedded element for thermal stability during extraction.
• Regulated extraction pressure. Over pressure valve (OPV) limits maximum pressure for optimal espresso flavour.
• Low pressure pre-infusion.
Gradually increases water pressure to gently expand grinds for an even extraction. Programmable.
• Dual pumps. Dedicated espresso and steam boiler pumps.
• Programmable shot temperature. Adjust water temperature to achieve optimal espresso flavour depending on coffee origin and degree of roast.
• One touch americano. Delivers hot water directly to the cup after espresso extraction. Preset and customizable settings.
• Shot clock. Displays duration of the espresso shot being extracted.
• Auto start and auto off. Switches machine on at a specified time and off after a specified time.

Specification

Included in the Box	Mini grinds bin, 58 mm full stainless steel portafilter, 1 cup & 2 cup single wall filter baskets, 16 oz stainless steel milk jug, steam wand spare parts, cleaning kit, water hardness test strip, water filter holder and water filter
Model Number	BES980BSS1BCA1
Milk Option	Programmable steam wand
Grinder	Yes
Heating System	Triple heat system: Dedicated steam boiler with integrated heat exchange, dedicated espresso boiler with digital PID control and heated group head to maintain thermal stability.
Water Filter Compatibility	Breville Charcoal Water Filter
Water Tank Capacity	84 oz.
Pump Pressure	9 bar (15 bar Italian pump)
User Interface	Buttons
Beverage Varieties	Double & Single Espresso, Hot Milk, Hot Water
Other Settings	Programmable shot volume, adjustable milk froth texture (3 levels), adjustable milk temperature (3 levels), steam button
Temperature Settings	Programmable shot temperature from 190 - 205F
Heat Up Time	1 minute
Grinder Settings	N/A
Coffee Grinds Hopper Capacity	1/2lb
Coffee Grounds Container Capacity	N/A
Coffee Powder Option	N/A
E.S.E. Pod Compatibility	No
Double Cup	No
Milk Double Cup	No
Removable Brew Group	No
Removable Drip Tray	Yes
Cleaning Routine	Descale, flush process
Certifications	N/A
Auto Off	No, machine will go into stand-by mode
Dimensions	16.25 x 15 x 18
Power / Voltage	1800 W / 110-120 V
Materials	Stainless steel dual boiler, brushed stainless steel exterior
Country of Origin	China

Use & Care

For detailed care instructions, please refer to your machines user manual. We recommend that you also incorporate the following into your cleaning routine:

• Descale every 2-3 months. We recommend using Breville The Descaler.
• Soap out water tank (if applicable) and drip trays every few days
• Keep the stainless steel casing shiny with a microfiber cloth
• Optional: Perform backlash routine and clean the filter basket each week.
